With the Q-MaxX HPC high-performance cutter, AVANTEC once again proves what our brand stands for: maximum performance, absolute precision, and uncompromising quality.

AVANTEC advantages that make the difference:

• Superior metal removal rate thanks to innovative AVANTEC cutting-edge geometry

• Flexibility made by AVANTEC: 2xD, 3xD and long versions for every machining depth

• Highest process reliability – robust, low-vibration, dependable

• Longer tool life and improved surface quality with AVANTEC high-end coatings

• Boost productivity, reduce costs through shorter machining times

Der Q-MaxX is more than just a tool – it is an AVANTEC promise of performance: Efficiency. Precision. Durability.

Versatile in Plunge and Face Milling: The robust end cutting edge and solid indexable insert deliver maximum material removal rates with high cutting length and large feed per tooth – ideal for efficient cast material machining.

• Maximum performance in plunge and face milling

• Strong in castings – fast, robust, efficient

• High feeds, high cutting speeds, maximum productivity

• Multifunctional thanks to solid indexable insert

Diameter 50 – 100 mm

Length of cut SL 48 – 89 mm

Z_eff 3 – 6

• Crosscut angle 90°

• Economical with 8-edged tangential SN indexable insert

• Robust and easy-cutting and ideal for machining cast iron

Kappa angle 90°

Diameter 50 – 160 mm

a_p Depth of cut 9.0 mm

h_max 0.15 – 0.28 mm

• The versions with Ø 16-50 mm are optimal for powerful milling on live tooling lathes and machining centers with rather low rigidity and drive power

• DIN tool holders with standard adaptation shank and spindle connection for HSK, Capto and SK

• Suitable for universal use, with 4-cutting edge UDGT indexable insert, in particular for high alloy steels

• “Soft” cutting ensures maximum metal removal rate Q even in case of extreme overhang

• Ideal for pocket milling

• Remarkable finishing quality even at high feed rates

• Excellent surface quality

Ramp angle 0.8° – 4°
Diameter 16 – 160 mm
a_p Depth of cut 1.0 – 3.0 mm
f_z Feed rate per tooth 0.45 – 2.1 mm

The GN18 is a standard milling cutter. It slits and severs. It has double-cutting edge indexable inserts that are positively connected. This makes the GN18 extraordinarily reliable. And fast. Moreover, it boasts a compact design. To accommodate more teeth. They deliver… more Q.

• 2-cutting edge indexable insert

• Cutting width from 2.5 mm

• Excellent cutting force dissiption

• Narrow tooth pitch

• High feed rates

Diameter 80 – 160 mm
Width of cut B_(h11) 2 – 3.5 mm
Z_eff 8 – 22
Width of cut 18 – 44 mm

• For universal use in cast iron and steel machining

• Excellent surface quality due to wiper geometry

• Variable clamping wedge system suitable for long- and short-chipping materials

Kappa angle 60°
Diameter 80 – 200 mm
a_p Depth of cut 10 mm
h_max 0.3 – 0.55 mm

• Well suited for the powerful machining of stainless steel materials

• Optimal chip removal through improved cutting edge geometry

• All diameters with internal cooling

Kappa angle 45°
Diameter 50 – 160 mm
a_p Depth of cut 4.5 mm
h_max 0.22 – 0.65 mm

• Highly precise finishing cutters with cartridge system

• Simple handling in setting and insert replacement

• Excellent surface quality with 4-cutting edge SN indexable insert

• Very wide wiper edge for optimum use in cast materials

Axial run-out < 0.005 mm
Kappa angle 90°
Diameter 63 – 160 mm
a_p Depth of cut 0.1 – 0.3 mm

• 4-cutting edge CN indexable insert

• Fine tooth pitch through tangential insert design

• Very smooth cutting through left and right hand inserts

• Secondary cutting edge positioned outside of the cutting zone

• Face milling possible with CB18

Depth of cut 10 – 14 mm
Kappa angle + groove machining 90°
Diameter 100 – 160 mm
Width of cut 25 – 50 mm
h_max 0.05 – 0.16 mm

• Extremely smooth cutting through left and right hand inserts

• Highly precise widths of cutfrom 4-12 mm

• Complies with narrow radial and axial run out tolerances

• 3-side embedding of the T-style indexable insert

Depth of cut 4 – 12 mm
Kappa angle + groove machining 90°
Diameter 63 – 250 mm
Width of cut 12 – 89 mm
h_max 0.05 – 0.20 mm

• Modular disc design

• Custom cutting lengths up to 2.5 x D

• Dual positive/negative helix reduces the axial impact of tractive and compressive forces

a_p Depth of cut up to 2,5 x D
Kappa angle 90°
Diameter 63 – 100 mm
h_max 0,10 – 0,25 mm

New in our program: Our first Plunge milling cutter

The 4-edged tangential insert allows radial depth of cut up to 12,5 mm and features a precise 90° groove bottom. The integrated stabilization chamfer ensures vibration-free operation – even with long overhangs – delivering maximum precision and efficiency in machining.

• 4–edged tangential insert

• Radial depth of cut up to 12,5 mm

• 90° groove bottom

• Stabilization chamfer for vibration-free operation

• Even suitable for long overhangs

  Diameter50 – 100 mm
  Z_eff3 – 7a_e radial
  up to 12,5 mm

• Kappa 75° – combined with the robust cutting edges permit both, high tooth feed rate and excellent surface quality

• 8-cutting edge, tangential SN indexable insert

• Maximum metal removal rate combined with high process reliability

Kappa angle 75°
Diameter 50 – 125 mm
a_p Depth of cut 5 mm
h_max 0.16 – 0.28 mm

• 4-cutting edge EN indexable insert

• Fine tooth pitch through tangential insert design

• Very smooth cutting through left and right hand inserts

• The secondary cutting edge ispositioned outside of the cutting zone

Depth of cut 14 – 24 mm
Kappa angle + groove machining 90°
Diameter 125 – 250 mm
Width of cut 32 – 78 mm
h_max 0.08 – 0.25 mm

• Alternative to carbide shank end milling cutters in combination with small depths of cut

• Utmost change accuracy

• Form and force locking cross and/or star drive keys

• Ensures maximum smooth cutting

Kappa angle 90°
Diameter 14 – 20 mm
a_p Depth of cut 6.0 + 8.0 mm
h_max 0.08 – 0.2 mm

• The RDGX indexable insert with facets prevents twisting and defines the fixation in the tool body

• The axial and radial cutting angle guarantees a soft cut

Ramp angle 2.0° – 5.0°
Diameter 20 – 125 mm
a_p Depth of cut 5.0 – 8.0 mm
f_z Feed rate per tooth 0.25 – 0.75 mm

• The versions with Ø 25-40 mm are optimal for powerful milling on live tooling lathes and machining centers with rather low rigidity and drive power

• DIN tool holders with standard adaptation shank and spindle connection for HSK, Capto and SK

• Maximum break resistance through tangential mounting of the 4-cutting edge CN indexable insert

• High combined feed per tooth and depths of cut

• CV90: Fine tooth pitch is an advantage in cast iron machining processes

Kappa angle 90°
Diameter 25 – 125 mm
a_p Depth of cut 7.5 – 10.0 mm
h_max 0.10 – 0.21 mm

• Highly compatible with materials that are difficult to machine, such as stainless and titanium

• High feed per tooth and depths of cut in 90°-machining

• The new screw-in versions with Ø 25-40 mm are optimal for powerful milling on live tooling lathes and machining centers with rather low rigidity and drive power

Kappa angle 90°
Diameter40 – 100 mm
a_p Depth of cut 8.0 – 10.0 mm
h_max 0.08 – 0.25 mm

• High feed milling cutter with high precision interchangeable carbide head system

• Optimal power transmission through cross or star drive keys

• Extreme stability for a long tool life

Ramp angle 2.3° + 3.8°
Diameter 16 – 25 mm
a_p Depth of cut 0.75 + 0.80 mm
h_max 0.35 – 1 mm

• Standard for all circlip grooves

• Three-side embedding of the circular indexable insert

• Ideal for groove bottom machining

Diameter 25 + 40 mm
a_p Depth of cut 1.4 – 2.2 mm
h_max 0.06 – 0.1 mm
